Referință | d1 | d2 | d3 | B1 | L | t1 | t2 | z1 | z2 | z3 | Găurire Ø da |
Greutate, kg | BX | PU |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
612630 | 40 | 20 | 50 | 85 | 120 | 50 | 66 | 32 | 105 | 8 | 25 | 0,380 | 30 | 240 |
616473 | 40 | 25 | 50 | 85 | 120 | 50 | 83 | 32 | 122 | 8 | 25 | 0,380 | 30 | 240 |
616474 | 40 | 32 | 50 | 85 | 120 | 50 | 86 | 32 | 125 | 8 | 25 | 0,390 | 30 | 240 |
616475 | 50 | 20 | 50 | 95 | 120 | 50 | 66 | 37 | 108 | 8 | 25 | 0,380 | 28 | 224 |
612702 | 50 | 25 | 50 | 95 | 120 | 50 | 83 | 37 | 125 | 8 | 25 | 0,390 | 28 | 224 |
615080 | 50 | 32 | 50 | 95 | 120 | 50 | 86 | 37 | 128 | 8 | 25 | 0,400 | 28 | 224 |
612631 | 63 | 20 | 50 | 108 | 130 | 50 | 66 | 51 | 100 | 10 | 25 | 0,440 | 20 | 160 |
612633 | 63 | 25 | 50 | 108 | 130 | 50 | 83 | 51 | 118 | 10 | 25 | 0,450 | 20 | 160 |
612632 | 63 | 32 | 50 | 108 | 130 | 50 | 86 | 51 | 123 | 10 | 25 | 0,460 | 20 | 160 |
616472 | 63 | 40 | 50 | 108 | 160 | 50 | 115 | 51 | 165 | 10 | 30 | 0,860 | 16 | 128 |
616334 | 63 | 63 | 50 | 108 | 160 | 50 | 115 | 51 | 165 | 10 | 30 | 0,640 | 16 | 128 |
616482 | 75 | 32 | 50 | 120 | 130 | 50 | 86 | 57 | 126 | 10 | 25 | 0,480 | 24 | 192 |
616483 | 90 | 20 | 50 | 137 | 160 | 50 | 66 | 66 | 106 | 10 | 30 | 0,610 | 14 | 112 |
616484 | 90 | 25 | 50 | 137 | 160 | 50 | 83 | 66 | 123 | 10 | 30 | 0,620 | 14 | 112 |
612634 | 90 | 32 | 50 | 137 | 160 | 50 | 86 | 66 | 126 | 10 | 30 | 0,630 | 14 | 112 |
615656 | 90 | 40 | 50 | 137 | 160 | 50 | 115 | 66 | 168 | 10 | 30 | 0,970 | 14 | 112 |
616476 | 90 | 50 | 50 | 137 | 160 | 50 | 115 | 66 | 168 | 10 | 30 | 0,990 | 14 | 112 |
612701 | 90 | 63 | 50 | 137 | 160 | 50 | 115 | 66 | 168 | 10 | 30 | 0,750 | 14 | 112 |
616487 | 110 | 20 | 50 | 152 | 160 | 50 | 66 | 76 | 111 | 10 | 30 | 0,620 | 14 | 112 |
616488 | 110 | 25 | 50 | 152 | 160 | 50 | 83 | 76 | 128 | 10 | 30 | 0,630 | 14 | 112 |
612637 | 110 | 32 | 50 | 152 | 160 | 50 | 86 | 76 | 134 | 10 | 30 | 0,650 | 14 | 112 |
615662 | 110 | 40 | 50 | 152 | 160 | 50 | 115 | 76 | 175 | 10 | 30 | 0,980 | 14 | 112 |
616477 | 110 | 50 | 50 | 152 | 160 | 50 | 115 | 76 | 175 | 10 | 30 | 0,990 | 14 | 112 |
612624 | 110 | 63 | 50 | 152 | 160 | 50 | 115 | 76 | 175 | 10 | 30 | 0,770 | 14 | 112 |
616491 | 125 | 20 | 50 | 167 | 160 | 50 | 66 | 83 | 111 | 10 | 30 | 0,650 | 12 | 96 |
616492 | 125 | 25 | 50 | 167 | 160 | 50 | 83 | 83 | 131 | 10 | 30 | 0,670 | 12 | 96 |
612649 | 125 | 32 | 50 | 167 | 160 | 50 | 86 | 83 | 138 | 10 | 30 | 0,670 | 12 | 96 |
615668 | 125 | 40 | 50 | 167 | 160 | 50 | 115 | 83 | 180 | 10 | 30 | 1,030 | 12 | 96 |
616478 | 125 | 50 | 50 | 167 | 160 | 50 | 115 | 83 | 180 | 10 | 30 | 1,120 | 12 | 96 |
612309 | 125 | 63 | 50 | 167 | 160 | 50 | 115 | 83 | 180 | 10 | 30 | 0,820 | 12 | 96 |
616495 | 140 | 32 | 50 | 170 | 160 | 50 | 86 | 91 | 141 | 10 | 30 | 0,710 | 12 | 96 |
616496 | 140 | 63 | 50 | 170 | 160 | 50 | 115 | 91 | 185 | 10 | 30 | 0,830 | 12 | 96 |
616497 | 160 | 20 | 50 | 195 | 160 | 50 | 66 | 106 | 108 | 10 | 30 | 0,750 | 10 | 80 |
616498 | 160 | 25 | 50 | 195 | 160 | 50 | 83 | 106 | 128 | 10 | 30 | 0,750 | 10 | 80 |
612641 | 160 | 32 | 50 | 195 | 160 | 50 | 86 | 106 | 137 | 10 | 30 | 0,760 | 10 | 80 |
615675 | 160 | 40 | 50 | 195 | 160 | 50 | 115 | 106 | 185 | 10 | 30 | 1,130 | 10 | 80 |
616480 | 160 | 50 | 50 | 195 | 160 | 50 | 115 | 106 | 185 | 10 | 30 | 1,130 | 10 | 80 |
612650 | 160 | 63 | 50 | 195 | 160 | 50 | 115 | 106 | 185 | 10 | 30 | 0,910 | 10 | 80 |
616501 | 180 | 20 | 50 | 203 | 190 | 50 | 66 | 116 | 110 | 10 | 30 | 0,790 | 10 | 80 |
616502 | 180 | 25 | 50 | 203 | 190 | 50 | 83 | 116 | 132 | 10 | 30 | 0,800 | 10 | 80 |
612651 | 180 | 32 | 50 | 203 | 190 | 50 | 86 | 116 | 141 | 10 | 30 | 0,820 | 10 | 80 |
616481 | 180 | 50 | 50 | 203 | 190 | 50 | 115 | 116 | 188 | 10 | 30 | 1,180 | 10 | 80 |
612652 | 180 | 63 | 50 | 203 | 190 | 50 | 115 | 116 | 188 | 10 | 30 | 0,950 | 10 | 80 |
612654 | 200 | 32 | 50 | 205 | 190 | 50 | 86 | 126 | 144 | 10 | 30 | 0,820 | 8 | 64 |
612659 | 200 | 63 | 50 | 205 | 190 | 50 | 115 | 126 | 190 | 10 | 30 | 0,950 | 8 | 64 |
612657 | 225 | 32 | 50 | 214 | 190 | 50 | 86 | 138 | 146 | 10 | 30 | 0,830 | 8 | 64 |
616486 | 225 | 50 | 50 | 214 | 190 | 50 | 115 | 138 | 197 | 10 | 30 | 1,210 | 8 | 64 |
612655 | 225 | 63 | 50 | 214 | 190 | 50 | 115 | 138 | 197 | 10 | 30 | 0,990 | 8 | 64 |
