Saddle with outlet spigot Universal SDR 11

Saddle with outlet spigot Universal SA UNI SDR 11

Gas, water and H2

Maximum pressure: Gas 10 bar, Water 16 bar
Material: PE 100
Universal clamping technique (balanced loading):
- Safe clamping with UNITOP
- Ideal distribution of force application
- Perfect adaptation to pipe diameter
Pressure test of the fusing before tapping possible
Tapping under pressure possible
Safety technology

Note:

When processing SA UNI with outlet spigot 90-160, the clamping device UNITOP (Order No. 613385) is required.

For the outlet spigots 225/250, UNITOP 250 (Order No. 617491) is required.

For pressure-free tapping, we recommend our FWAB drilling device.

Pressure test of the fusing before tapping with pressure test adapter FWDPA SA (Order No. 613596).

Also suitable for special dimensions for Close-Fit-Liners.

If you have any questions about this or about tapping under pressure, please contact our Hotline: Tel. +49 621 486-2325.

Go back

PE 100 SDR 11

Maximum permissible working pressure 16 bar (water) / 10 bar (gas)

Reference	d₁	d₂	B1	L	t	Drilling Ø d_a	Weight kg	BX	PU
616553	250-280	90	260	130	79	65	1,420	5	40
616554	250-280	110	260	140	82	84	1,590	5	40
616555	250-280	125	260	146	87	95	1,760	5	40
616556	250-280	160	260	158	98	123	2,210	5	40
616557	315-400	90	280	130	79	65	1,430	5	40
616558	315-400	110	280	140	82	84	1,600	5	40
616559	315-400	125	280	146	87	95	1,750	5	40
616560	315-400	160	280	158	98	123	2,220	5	40
616561	450-900	90	307	130	79	65	1,390	5	40
616562	450-900	110	307	140	82	84	1,550	5	40
616563	450-900	125	307	146	87	95	1,710	5	40
616564	450-900	160	307	158	98	123	2,160	5	40
617224	315-355	225	363	226	164	172	2,210	5	40
617225	315-355	250	363	226	164	187	2,210	5	40
617226	400-450	225	403	226	164	172	2,210	5	40
617227	400-450	250	403	226	164	187	2,210	5	40
617228	500-630	225	429	226	164	172	2,210	5	40
617229	500-630	250	429	226	164	187	2,210	5	40
617230	710-900	225	444	226	164	172	2,210	5	40
617231	710-900	250	444	226	164	187	2,210	5	40
617232	1000-1200	225	450	226	164	172	2,210	5	40
617233	1000-1200	250	450	226	164	187	2,210	5	40

Areas of Application

Instead of cost-intensively integrating a T-piece, a branch or vent can be very comfortably created using the FRIALEN Saddle with outlet spigot Universal SA UNI. The spigot outlet can be fused with FRIALEN couplers MB or UB.

Assembly Instructions

The saddle is clamped onto the pipe with the UNITOP clamping device (see FRIATOOLS product range). The clamping device UNITOP is an universal tool for all SA UNI dimensions. Please read the assembly and operating instructions for the clamping device UNITOP.

The fusion of the HD-PE distribution pipes and the house connections with FRIALEN Saddle with outlet spigot Universal SA UNI takes place by FRIALEN-fusing – leakproof and longitudinally strong.

The saddle and the outlet spigot have to be prepared according to the general installation instructions (see assembly instruction FRIALEN safety fittings). This involves removing the oxide skin and cleaning the pipe covered by the saddle.

For tapping of pipes without pressure please use the FRIATOOLS tapping equipment FWAB. Please refer the assembly and operating instructions of the drilling device FWAB. The fusion and tapping of pipes under pressure is possible with special tapping equipment. Please contact our applications engineers.

Good reasons for using the FRIALEN Saddle with outlet spigot Universal SA UNI:
