Microswitch IP 65
PNEUMATICALLY ACTUATED DIAPHRAGM VALVES
MAGNUM 3G is completed with a range of tools and accessories to help the installer
Main features:
- Upper part (PVC-U)
- Bottom part (PVC-U)
- Bolts (zinc plated steel)
- Nuts (zinc plated steel )
- Gasket (NBR)
- Reinforcing ring (Stainless steel)
| Reference | DN |
|---|---|
| ZMSFC001 | 15 ÷ 32 |
| ZMSFC002 | - |
| ZMSFC003 | 40 |
| ZMSFC004 | 50 ÷ 65 |
| ZMSFC005 | 80 ÷ 100 |
| ZMSFC006 | 25 ÷ 32 |
| ZMSFC007 | 40 |
| ZMSFC008 | 50 ÷ 65 |
| ZMSFC009 | 12 ÷ 15 |
- The reinforcing bush are used to reinforce the pipe PE100 (SDR11) e PE-X, to elong the lifetime of the pipeline and to reduce the collapse risk of the pipe in disadvantages conditions. They use is particurarly suggested using PE-X pipes. The two tightening keys (d.16-63 and d.75-110) are important tools to install the MAGNUM 3G fittings
