FBS
Actuating linkage for FRIALOC PE shut-off valves
Actuating linkage FBS for FRIALOC
- To operate the FRIALOC from the road cap downwards
- ClickFix (tool-free)
- Wrench size SW 30 (30 mm)
- Telescopic bar:
- Length fitting
- Continuously adjustable (without tools)
- Self-supporting
- Corrosion protected (actuating element and coupling sleeve made of hot-dip galvanised cast steel, linkage made of hot-dip galvanised steel)
Steel linkage, hot-dipped galvanised
| Reference | RD in m | lmin | lmax | sw2 | Weight kg | BX | PU |
|---|---|---|---|---|---|---|---|
| 616308 | 0,75 - 1,0 | 397 | 571 | 30 | 2,400 | 1 | 42 |
| 616309 | 0,9 - 1,3 | 552 | 881 | 30 | 4,200 | 1 | 42 |
| 616310 | 1,2 - 1,8 | 817 | 1441 | 30 | 5,400 | 1 | 42 |
| 616318 | 1,5 - 2,3 | 1035 | 1847 | 30 | 6,650 | 1 | 42 |
Area of application
Telescopic activation bar to operate the FRIALOC PE shut-off valve from the street cap.
Assembly instructions
Before fusion, the FRIALOC PE shut-off valve must be aligned corresponding to the planned
actuation to guarantee a correct positioning of the FRIALEN installation kit (FBS).
Good reasons for the installation kit FBS for FRIALOC PE shut-off valves:
- easy and safe installation thanks to KlickFix® system
- protective pipe of polyethylene protects from intrusion of sand or soil
- pull tight connection between FRIALOC and protective pipe: solid and dirt-proof
- assembly without tools
- self-supporting in all telescopic positions
- safe from being pulled out
- corrosion-protected
- telescopic installation kit can also be adjusted even once in place and filled
- constructive harmonizing of the transferable torque onto the FRIALOC PE shut-off valve
- Connexion pins made of stainless steel
